03/05 AWB2724-1453G
71
Appendix
Compatibility
The functional range of the XC-CPU101 is dependant on the hard-
ware (HW), the installed operating system (BTS) and the version of
the programming software (XSoft).
The following overview informs you about the functionality's in
dependance on the hardware, BTS and XSoft versions:
h
• The compatibility for older operating systems of the
XC101 is guaranteed.
• Due to the modified control configuration with existing
projects, it might be necessary that the control configu-
ration may need to be re-entered.
• If a project with a new control configuration is loaded
onto an XC101 with an older operating system version,
only the functions of the older operating system are
available for use.
Functionality Hardware version:
V01 V02 V04
From operating system version: XSoft version:
Basic functionality V1.2 – – F V2.2.5.+Rev. B
PRG default baud rate 57.6 kBit/s Only V1.2 – – V2.3.1
PRG default baud rate 38.4 kBit/s V1.3 – – V2.3.1
Multiple CAN users V1.3 – – V2.3.1
CAN Device V1.3 – – V2.3.1
Programming via CANopen (Routing) V1.3 – – V2.3.1
MMC access
– V2.0 – V2.3.1
Interrupt functionality – V2.0 – V2.3.1
RS232 interface in Transparent mode – V2.0 – V2.3.1
Peripheral direct access – V2.0 – V2.3.1
CAN direct access – V2.0 – V2.3.1
CAN baud rate up to 500 kBit/s
– V2.0 – V2.3.1
XI/OC bus expansion with XIOC-BP-EXT V1.3 – – V2.3.2
Introduction of the CAN bus load “canload” V1.3 – – V2.3.2
Storage of text data bank on the MMC V1.3 – – V2.3.2
Storage of project information on the MMC
V1.3 – – V2.3.2
System events warm and cold start V1.3 – – V2.3.2
Timer interrupt V1.3 – – V2.3.2
Serial interface module XIOC-SER
V1.3 – – V2.3.2
PROFIBUS-DP M module – – V3.01 V2.3.2
SUCONET K slave – – V3.02 V2.3.2
Update of the MMC's operating system – – V3.03 V2.3.2
PROFIBUS-DP S module – – V3.10 V2.3.2
Suconet K master module – – V3.10 V2.3.2
Diagnostics – – V3.10 V2.3.2
Free address specification – – V3.10 V2.3.2
