03/05 AWB2724-1453G
Technical data
73
Technical data
XC-CPU101-C...K-8DI-6DO(-XV)
General
Standards and regulations IEC/EN 61131-2
EN 50178
Ambient temperature °C
0 to +55
Storage °C
–25 to +70
Mounting position
Horizontal
Relative humidity, no condensation (IEC/EN 60068-2-30) %
10 to 95
Air pressure (in operation) hPa 795 to 1080
Vibration resistance 10 to 57 Hz g0.075 mm
57 to 150 Hz g1.0 g
Mechanical shock resistance 15 g/11 ms
Overvoltage category II
Pollution degree 2
Enclosure protection IP 20
Rated insulation voltage V 500
Interference emission EN 50081-2, Class A
Interference immunity EN 50082-2
Battery lifetime Worst case 3 years, typ. 5 years
Weight kg 0,23
Dimensions (W x H x D) mm 90 x 100 x 100
Connecting terminals Plug-in terminal block
Conductor cross-section
Screw terminals
Stranded with ferrule mm
2
0.5 to 1.5
Solid core mm
2
0.5 to 2.5
Spring-loaded terminal
stranded mm
2
0.14 to 1.0
Solid core mm
2
0.34 to 1.0
Electromagnetic Compatibility (EMC)
Electrostatic discharge IEC/EN 61000-4-2, Level 3, ESD)
Contact discharge kV 4
Radiated (IEC/EN 61 000-4-3, RFI) V/m 10
Burst Impulse (IEC/EN 61000-4-4, Level 3)
Supply cables kV 2
Signal cables kV 1
Surge (IEC/EN 61 000-4-5) kV
0,5
Conducted (IEC/EN 61 000-4-6) V 10
