-19-
Revision 7/F3512
© Moffat Ltd, January 2005
E35 Turbofan Ovens
FAULT POSSIBLE CAUSE REMEDY
OVEN LIGHTS NOT
ILLUMINATING
Blown bulb(s).
Faulty lighting transformer.
NOTE: If both light bulbs have
blown then there will be no
output from the lighting
transformer.
Replace.
(Refer service section 6.3.4)
Replace.
(Refer service section 6.3.6)
OVEN VENT INDICATOR NOT
ILLUMINATING WHEN IN ‘OPEN’
POSITION
Indicator faulty.
Switch faulty.
Replace.
(Refer service section 6.3.2)
Replace.
(Refer service section 6.3.23)
OVER-PRESSURE VENT NOT
OPERATING DURING STEAM
CYCLE
Vent blocked.
Over-pressure vent mechanism
restricted.
Remove and clean blockage.
Remove and clean.
DOOR DOES NOT CLOSE Tray in way of door.
Door seal obstruction.
Door handle in wrong position.
Door setting incorrect.
Correctly position tray in rack.
Correctly install door seal.
(Refer maintenance section)
Reposition door handle.
Adjust.
(Refer service section 6.4.3)
DOOR SEAL LEAKS Door seal damaged.
Door seal incorrectly fitted.
Replace.
(Refer maintenance section)
Correctly install door seal.
(Refer maintenance section)
RACKS DO NOT FIT Incorrect pin location. Relocate on correct pin.
