Moffat Turbofan E35 - Fan; Steam Flow Chart

-35-
Revision 7/F3512
© Moffat Ltd, January 2005
E35 Turbofan Ovens
T5
T4
C4 & C6
C5
C3
C2
T3
T2
T1
Timers T4 and T2 only operate when steaming (otherwise is direct connection).
Steam Timer
(10sec)
Dwell timer
(10sec delay)
Steam Timer
(10sec)
Cycle timer
1min 30sec
switching time
Door Switch
Power Switch
Power In
via 6A breaker
Dwell timer
(10sec delay)
Fan Direction
Contactor
Fan Direction
Contactor
Low Speed
Contactor
Motor
Hi Speed
Contactors
phase
change
Fan / Steam Flow Chart
This is a guide only, for accurate representation of all connections refer to the wiring chart.
Fan speed
switch selection
Anti-Clockwise
Fan Rotation
Clockwise
Fan Rotation
Steam
Switch
Steam
Switch
Water Solenoid
3 Phase Power
Steam switch on control panel - manual activation.
