-15-
Revision 7/F3512
© Moffat Ltd, January 2005
E35 Turbofan Ovens
IMPORTANT: THIS UNIT IS NOT
WATER PROOF.
DO NOT USE A WATER JET SPRAY TO
CLEAN INTERIOR OR EXTERIOR OF THIS
UNIT.
WARNING: ALWAYS TURN THE
POWER SUPPLY OFF BEFORE
CLEANING.
EXTERIOR
Clean with a good quality stainless steel cleaning
compound. Harsh abrasive cleaners may dam-
age the surface.
INTERIOR
Ensure that the oven chamber is cool. Do not use
wire brushes, steel wool or other abrasive materi-
als. Clean the oven regularly with a good quality
oven cleaner. Take care not to damage the fan
or the tube at the right side of the oven which
controls the thermostat.
SIDE RACKS
To remove, follow instructions given in the
installation section.
OVEN DOOR (HINGED GLASS)
Outer surfaces: Clean with conventional glass
cleaners
Inner surfaces: To clean between the inner and
outer door glasses, firstly ensure the door is
locked shut. With a screwdriver, coin, or other
suitable device,
1
/
4
turn the outer glass locks to
release the outer glass and allow it to be hinged
open for cleaning access (refer to figure 4.1 for
correct procedure).
4. MAINTENANCE
4.1 CLEANING
WARNING: ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED OUT BY
QUALIFIED PERSONS ONLY.
TOP
LOCKED
BOTTOM
UN-LOCKED
UN-LOCKED
LOCKED
Figure 4.1
Figure 4.2
OVEN DOOR (HINGED GLASS)
Outer surfaces: Clean stainless steel with quality
stainless steel cleaner.
Inner surfaces: Clean stainless steel with
quality stainless steel cleaner.
Door glass: Clean with conventional glass
cleaners.
OVEN SEALS
To remove, pull out the seal starting at each
corner. The seal may be washed in the sink, but
take care not to cut or damage it. To replace, fit
the seal in at the corners first, then push in the
rest of the seal.
IMPORTANT: ALWAYS ENSURE
THAT THE OUTER GLASS IS HINGED
CLOSED AND LOCKED INTO
POSITION BEFORE OPENING DOOR.
