6.3.19 BUZZER
1) Remove R/H service panel (refer 6.2.2).
2) Remove two screws holding buzzer bracket
to panel.
6.3.18 BAKE TIMER
1) Remove bake timer knob by pulling it firmly
away from control panel.
2) Open control panel (refer 6.2.1) and undo two
screws securing timer.
3) Transfer wires to new timer.
4) Withdraw old timer and insert new timer, se-
curing with screws.
5) Replace knob.
6) Check timer switches off at ‘0’ mark. If slight
adjustment required, loosen the mounting
screws and rotate timer in direction required.
3) Withdraw and transfer wires to new buzzer.
4) Remove old buzzer from bracket, and secure
new buzzer.
5) Reassemble in reverse order.
Figure 6.3.29
6.3.20 FAN
1) With service panel and oven fan baffle
removed (refer 6.2.2 & 6.2.3) undo the 6 bolts
holding the probes and steam line.
6.3.17 COOLING FAN
1) Remove R/H service panel (refer 6.2.2).
2) Remove the fan wires from the contactors.
Six Bolts
Figure 6.3.31
Figure 6.3.26
2) Remove the 4 screws securing the fan to it’s
mounting bracket and remove fan.
NOTE:
There is a nut on each screw, hold the
nut while undoing the screw.
Figure 6.3.27
3) Replace and re-assemble in reverse order.
4) Ensure fan and flow direction is correct -
sucks air out of controls and into motor cavity.
Figure 6.3.28
Two Screws
Figure 6.3.30
