Moffat Turbofan E35 - MOTOR & ELEMENTS; STEAM SYSTEM; DOOR

-43-
Revision 7/F3512
© Moffat Ltd, January 2005
E35 Turbofan Ovens
MOTOR & ELEMENTS
020745 Motor - 380-415V 50Hz 3ø
(E35-H453-xx, E35-N453-xx, E35-X353-xx only)
020885 Motor - 220-240V 50Hz 1ø/3ø
(E35-H251-xx, E35-X25x-xx only)
020886 Motor - 208-240V 60Hz 1ø/3ø
(E35-P26x-xx, E35-T26x-xx, E35-X263-xx only)
---------- Motor Front Bearing - SKF 6204-2Z/C3LHT23
---------- Motor Rear Bearing - NSK 6203Z
025396 Fan
020896 Motor Shaft Seal
020762 Element - 230-240V 2000W
(E35-Hxxx-xx, E35-Nxxx-xx, E35-Txxx-xx only)
020763 Element - 208-220V 2000W
(E35-Pxxx-xx, E35-Xxxx-xx only)
022259 Element - 208-220V 1250W
(E358-Nxxx-xx only)
STEAM SYSTEM
020851 Water Solenoid Valve
020853 Spray Adaptor Body
020854 Spray Nozzle Cap
020819 Vent Over Pressure Spring
020824 Vent Gasket
DOOR
025043 Door Seal
020738 Hinge Bush
020754 Bolt Catch
020750 Hinge Mounting Plate Bottom
023050 Hinge Mounting Plate Top
020753 Bolting Element
020833 Door Bolt Connecting Rod
020752 Handle Gear
020751 Door Handle
020774 Microswitch
020766 Latch Assembly (Hinged glass door only)
020713K Door Inner Glass (Hinged glass door only)
022308 Glass Clamp (Hinged glass door only)
021154 Door Outer Glass Assembly (Hinged glass door only)
024150 Door Glass Assembly - Complete (Stainless steel door only)
(NOTE:
Does not include inner and outer seals)
024094 Door Inner Glass (Stainless steel door only)
024095 Door Outer Glass (Stainless steel door only)
024104 Door Inner Glass Seal (Stainless steel door only)
024105 Door Outer Glass Seal (Stainless steel door only)
024087 Door Inner Glass Clamp Frame (Stainless steel door only)
PART NO DESCRIPTION
