Molecular Devices ImageXpress Pico User Manual

ImageXpress Pico Automated Cell Imaging System Installation Guide
10 5063666 K
To replace fuses:
1. If the instrument is powered on, press the Power button on the front of the instrument to
turn off the power.
When the status light on the Power button is amber, the instrument is fully powered off.
Note: If the ImageXpress Pico system doesn't respond, you can perform a hard
shutdown by holding the Power button for five seconds.
2. Disconnect the power cord from the power port.
3. Gently press on the carrier-release tab (below the power port) with a small flat-head
screwdriver, and pull the fuse carrier to remove it from the instrument.
4. Gently pull the old fuses from the carrier by hand.
5. Gently place the new fuses into the carrier.
6. Press the fuse carrier into the instrument until the carrier snaps into place.
7. Connect the power cord into the power port.
8. Press the Power button to power on the instrument.
When the light on the Power button is green, the instrument is fully powered on.
Note: If the instrument still does not power on after replacing fuses, contact Molecular
Devices Technical Support. See Obtaining Support on page 20 for details.

Molecular Devices ImageXpress Pico Specifications

General

Brand	Molecular Devices
Model	ImageXpress Pico
Category	Laboratory Equipment
Language	English
