Molecular Devices ImageXpress Pico User Manual

5063666 K 65
Appendix A: Instrument Specifications
The instrument must be installed on a level and stable surface.
WARNING!
If the instrument is used in a manner not specified by Molecular Devices, the
protection provided by the equipment might be impaired.
The ImageXpress Pico system is an Equipment Class 1 product that relies on
protective earth grounding for safe operation. Any interruption of the protective
earth ground conductor, inside or outside the instrument, or disconnection of the
protective earth ground terminal can result in personal injury.
Item Description
Operating Environment Indoor use only
System Power 100 VAC to 240 VAC, 50/60 Hz, 1.6 A nominal at 115 V, 200 W
maximum
Fuses 5mm x 20mm 6A MEDIUM 250V UL CSA ceramic tube
Dimensions without environmental control system
Width:55.1cm (21.7in.)
Height: 45.3cm (17.8in.)
Depth: 42.5cm (16.7in.)
with environmental control system
Width:62.9cm (24.7in.)
Height: 45.3cm (17.8in.)
Depth: 51.6cm (20.3in.)
Front Clearance (for maintenance
door)
19.5cm (7.68in.)
Rear Clearance (for ventilation
and cable connections)
20cm to 30cm (7.9in. to 11.8in.)
Top Clearance 23.1cm (9.1in.)
Weight without environmental control system
38kg (83.8lb)
with environmental control system
40kg (88.2lb)
Sample Formats, dishes (optional) Standard culture dishes, 35mm (1.38in.)
Sample Formats, microplates ANSI/SLAS compliant
Number of Wells:6, 12, 24, 48, 96, 384
Maximum Height, including lid: 23mm (0.9in.)
Sample Formats, slides Standard microscope slides, 25mm x 75mm (1in. x 3in.)
A
