Molecular Devices ImageXpress Pico User Manual

Chapter 4: Finishing Setup of the ImageXpressPico System
5063666 K 47
Inserting the Slide Holder
Like the sample stage, the slide holder also has an A1 label to indicate its top left corner.
To insert the slide holder:
1. Press the button at the top right of the instrument to open the top door.
2. With the A1 label at the top left (as shown), insert the slide holder in the sample stage.
Note: The pin at the bottom right of the slide holder should fit into the small recess
in the sample stage.
3. Confirm that the slide holder is seated flat in the sample stage.
4. Press the button at the top right of the instrument to close the top door.
