ImageXpress Pico Automated Cell Imaging System Installation Guide
56 5063666 K
6. Do the following to connect the humidifying column:
Note: See Connecting and Disconnecting Tubing on page 58 for details on
connecting tubing.
a. Align the red dots to connect the electronics cable to the lower port on the
humidifying column.
b. Connect the tubing with the blue band to blue port on the humidifying column.
c. Connect the tubing with the red band to red port on the humidifying column.
