1.5 Hardware Description
The main features of the card are described in more detail in the following sections.
For information on card dimensions, refer to Section B.1,
Technical Specifications.
Figure 1: The SST-DN4-PCU Interface Card
Card Components
Feature Description
1 Channel A HLTH LED (top)
2 Channel A CAN Connector
3 Channel A COMM LED (bottom)
