SST-DN4-PCU Hardware Reference Guide
1.5.2 LEDs
There are two LEDs per channel: Health (HLTH) and Communications (COMM).
Note
For information on troubleshooting using LEDs, refer to Section 4.1,
HLTH LED is Red.
Figure 3: Mounting Bracket, Front View
Table 2: LED Descriptions
Feature Description
1 Channel A HLTH LED
2 Channel A COMM LED
18 Card Overview
©2009 Molex Inc.Automation & Electrical Products, Integrated Products Division
Document Edition: 1.0, Document #: 715-0101, Template Edition: 1.1, Template #: QMS-06-045
Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.
