Hardware Reference Guide SST-DN4-PCU
Installation 23
©2009 Molex Inc.Automation & Electrical Products, Integrated Products Division
Document Edition: 1.0, Document #: 715-0101, Template Edition: 1.1, Template #: QMS-06-045
Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.
2.3 Installing the Card
To install the card in your computer:
1. Ensure that all power to your computer is off.
2. Adequately ground yourself, as cautioned in Section 2.2,
Handling Precautions.
3. Unplug the power cord, modem (if applicable), and any network cables.
4. Remove the computer cover. Consult your computer user’s guide for information on
installing add-in boards.
5. Take the card out of its shipping container and anti-static bag, being careful not to touch
any of the connectors or pins.
6. Firmly press the card into a compatible PCI-compliant connector.
7. Secure the card using the screws provided. Re-connect any items unplugged in Step 3.
8. Replace the computer cover and power up the machine.
9. Connect the card to the DeviceNet network, as explained in the following section.
