SST-DN4-PCU Hardware Reference Guide
46 Technical Specifications
©2009 Molex Inc.Automation & Electrical Products, Integrated Products Division
Document Edition: 1.0, Document #: 715-0101, Template Edition: 1.1, Template #: QMS-06-045
Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.
B.1 Technical Specifications
The following tables list the technical specifications for the card.
Table 19: Environmental Specifications
Ambient Conditions Storage temp:
-40°C to +85°C
Operating temp:
0°C to 60°C
Humidity: 5% to 95% non-condensing
Typical Current Draw +5V, +/-5%, 0.3 A (1-channel)
Table 20: Network Specifications
Cable Shielded twisted pair, compatible with target network
External Power 11-24 VDC, 50mA (typical)
Isolation 500V
Protocol CAN 2.0 A/B
Data Rate Up to 1M baud for CAN
125K, 250K and 500K baud for DeviceNet
