Hardware Reference Guide SST-DN4-PCU
Technical Specifications 47
©2009 Molex Inc.Automation & Electrical Products, Integrated Products Division
Document Edition: 1.0, Document #: 715-0101, Template Edition: 1.1, Template #: QMS-06-045
Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.
PCI Bus Specifications
Compliance Compatible with PCI 2.2; will operate in
2.3 and some 2.1-compliant systems.
Refer to Table 1:
PCI Compatibility Table, for
more information.
Size
Standard half-length, 32-bit, 33MHz, universal
PCI card
Resources (memory) 2K window for Card only
(memory) 256KB window available to the host
per channel
(I/O) 16 bytes allocated for channel
(I/O) 128 bytes for PCI configuration,
per card
