SST-DN4-PCU Hardware Reference Guide
3.3 Resource Allocation
Table 5: DN4-PCU Allocation
Resource Total Allocated Channel Allocation
Memory 256KB 256KB block
I/O
16-byte range 16-byte block
Resource usage corresponds to
the Host Register Layout.
3.4 DN4 Card Configuration Registers
This section provides hardware register details for the card.
3.4.1 Host Register Layout
The channel has its own set of registers, located in I/O space.
Note
Upon card power up, or after a physical reset from the system, it
typically takes 1 second for the channel to initialize (though it is
recommended that applications wait up to 2 seconds). Initialization can
be confirmed by monitoring the LEDs or by reading the FamilyID
register, as described in Section C.1.1, Verify Card Presence.
30 Hardware Register Details
©2009 Molex Inc.Automation & Electrical Products, Integrated Products Division
Document Edition: 1.0, Document #: 715-0101, Template Edition: 1.1, Template #: QMS-06-045
