SST-DN4-PCU Hardware Reference Guide
44 Error Messages
©2009 Molex Inc.Automation & Electrical Products, Integrated Products Division
Document Edition: 1.0, Document #: 715-0101, Template Edition: 1.1, Template #: QMS-06-045
Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.
A.1 Introduction
Error messages are posted in the Host Interface Memory’s message area (0040h) and can be
displayed using one of the status applications, such as DNSTAT, provided with the card.
For details on the shared Host Interface Memory layout, refer to the Firmware Reference Guide.
A.2 FamilyID Messages
If FamilyID reads anything other than 0x40, the card has not been found. Check for
memory and I/O conflicts. If you continue to experience difficulties, refer to Section 4.4,
General Troubleshooting.
A.3 Fatal Hardware Self-Test Flash Codes
Fatal failures during startup are accompanied by an 8-bit fault code, flashed on the Health Led.
The fault code will be output MSB first, with a 1 (one) bit shown as a green LED, and a zero (0)
bit shown as a red LED. This will occur for a period of 900ms, followed by 100ms of off time.
The LSB will be followed by an additional 1000ms of off time, after which the sequence will
repeat.
The following table describes each possible fault code.
Table 18: LED Flash Codes
Value Flash sequence Left-
>Right
Description
0x10 R-R-R-G-R-R-R-R Invalid/non-existent boot loader in Flash
0x11 R-R-R-G-R-R-R-G Flash ID Invalid
0x12 R-R-R-G-R-R-G-R Flash read error
0x13 R-R-R-G-R-R-G-G Shared memory error
0x14 R-R-R-G-R-G-R-R Local memory failure
0x15-FF - Reserved for firmware-specific fatal errors
