Output
Sensor supply 24 VDC / 50 mA; 10 VDC / 20 mA
Analog output 0/4-20 mA / burden 350 Ohm; 0-10 VDC / burden 10 kOhm,
16 bit
Switching outputs
Relay with change-over
contacts
Switching cycles
250 VAC / 5 AAC; 30 VDC / 5 ADC
30 x 10
3
at 5 AAC, 5 ADC ohm resistive burden
10 x 10
6
mechanically
Diversification according to DIN EN50178 /
Characteristics according to DIN EN60255
Power supply 230 VAC ± 10 % max. 10 VA
10-30 VDC galv. isolated, max. 4 VA
Memory EEPROM
Data life ≥ 100 years at 25°C
Ambient conditions
Working temperature 0°…50°C
Storing temperature -20°…80°C
Weathering resistance Relative humidity 0-80% on years average without dew.
EMV EN 61326
CE-sign Conformity according to directive 2014/30/EU
Safety standard According to low voltage directive 2014/35/EU
EN 61010; EN 60664-1
35
9. Technical data
