9. Technical data
Housing
Dimensions 96x48x70 mm (BxHxD)
96x48x89 mm (BxHxD) including plug-in terminal
Panel cut-out 92.0
+0.8
x 45.0
+0.6
mm
Wall thickness up to 15 mm
Fixing screw elements
Material PC Polycarbonate, black, UL94V-0
Sealing material EPDM, 65 Shore, black
Protection class standard IP65 (Front), IP00 (Back side)
Weight approx. 200 g
Connection plug-in terminal; wire cross-section up to 2.5 mm
2
Display
Digit height 14 mm
Segment colour red (optional green, orange or blue)
Display range -19999 up to 99999
Setpoints one LED per setpoint
Overflow horizontal bars at the top
Underflow horizontal bars at the top
Display time 0.1 to 10.0 seconds
Input Measuring
range
Ri Measuring error Digit
min. -22…max. 24 mA 0/4 – 20 mA ~100 Ω 0.1 % of measuring
range
±1
min. -12…max. 12 VDC 0 – 10 VDC ~200 kΩ 0.1 % of measuring
range
±1
Digital input < 2.4 V OFF, 10 V ON, max. 30 VDC
R
I
~ 5 kΩ
Accuracy
Temperature drift 100 ppm / K
Measuring time 0.1…10.0 seconds
Measuring principle U/F-conversion
Resolution approx. 18 bit at 1s measuring time
