montwill M2 - Electrical Connection

3. Electrical connection
3
3. Electrical connection
Type M2-1VT5B.0001.470xD with a supply of 115 VAC
Type M2-1VT5B.0001.570xD with a supply of 230 VAC
Type M2-1VT5B.0001.670xD with a supply of 10-30 VDC
0/4....20 mA
+
0...10 V
_
+
Sensor
supply
(Option)
_
+
1 2 3 10 119
4 5 6 7 8
0-10 VDC
+
Digital input
(Option)
10-30 VDC
or
115 VAC
or
230 VAC
N L
7 8 9
_
+
0/4-20 mA
Analog output
(Option)
21 22 23 24 25 26
S1
S2
Relay option
_
+
