5. Setting up the device
27
Menu level Parameterisation level
Alarms for relay 2,
Default:
The allocation of the alarms to relay 2 happens via this parameter, one alarm or a
group of alarms can be chosen. This parameter can only be selected if was
selected under . With [P] the selection is confirmed and the device changes
into menu level.
Back to menu group level,
With [P] the selection is confirmed and the device changes into menu group level
.
Menu group level
5.4.6. Alarm parameters
Menu level
Menu level Parameterisation level
Dependency of alarm 1,
Default:
The dependency of alarm 1 can be related to special functions, in detail these are
the current measurand, the min/max-value, the totaliser value/sum value, the
sliding average value, the constant value or the difference between the current
measurand and the constant value. If was selected, the alarm is hold and
processed just after deactivation of . causes the dependency either by
pressing the [O]-key on the front of the housing or by an external signal via the
digital input. With [P] the selection is confirmed and the device changes into menu
level.
Example: By using the maximum value = in combination with a
threshold monitoring , an alarm confirmation can be realised. Use the
navigation keys or the 4th key for confirmation.
….
