5. Setting up the device
21
Menu level Parameterisation level
Back to menu group level, :
With [P] the selection is confirmed and the device changes into menu group level
.
Menu level Parameterisation level
Adjustment of user code,
Default:
Via this code reduced sets of parameters and can be released during
locked programming. Further parameters are not available via this code. The
can only be changed via the correct input of the (Master code).
Master code, :
Default:
By entering the device will be released and all parameters unlocked.
Release/ lock analog output parameters,
Default:
Analog output parameters can be locked or released for the user:
- the initial or final value can be changed in operation mode.
- the output signal can be changed from e.g. 0-20 mA to 4-20 mA
or 0-10 VDC.
- analog output parameters are released.
- all analog output parameters are locked.
Menu group level
5.4.3. Safety parameters
Menu level
