5. Setting up the device
29
Menu level Parameterisation level
Totaliser state,
Default:
The totaliser makes measurements on a time base of e.g. l/h possible. There the
scaled input signal is integrated by a time and steadily (select ) or temporarily
(select ) saved. Choose the quick storage for numerous filling processes and
the permanent storage for consumption measurings. At the permanent storage
, the current cumulative value is saved at each totaliser reset and further-
more, every 30 minutes in the non-volatile memory of the device. If is selected,
the function is deactivated. With [P] the selection is confirmed and the device
changes into menu level.
Time base,
Default:
Under this parameter the time base of the measurement can be preset in seconds,
minutes or hours.
Totaliser factor, :
Default:
Here the factor (10
0
…10
6
) respectively the divisor for the internal calculation of the
measuring value is assigned.
Setting up the decimal point for the totaliser,
Default:
The decimal point of the device can be adjusted with the navigation keys [▲] [▼].
With [P] the selection is confirmed and the device changes into menu level.
Menu group level
5.4.7. Totaliser (Volume metering)
Menu level
…
