5. Setting up the device
24
Menu group level
5.4.5. Relay functions
Menu level
Menu level Parameterisation level
Alerting relay 1,
Default:
Each setpoint (optional) can be linked up via 4 alarms (by default). This can either
be inserted at activated alarms or deactivated alarms . If was
selected, logical links are available in the menu levels and . Access to
these two menu levels is via , at all other selected functions, these two
parameters are overleaped. Via the setpoints can be activated/deactivated,
in this case the output and the setpoint display are set/not set on the front of the
device. The parameters , and can only be used in accordance with
the semi-automatic calibration (Chapter 8. Sensor alignment). At the relay
switches during sensor calibration, at during offset calibration and at
during the calibration of the final value. With [P] the selection is confirmed and the
device changes into menu level.
….
….
