TheBladeAssembly
Ifthebladesetismisaligned,themediabeingdrivenwillbesubjecttoscoringoreven
tearingatanypointalongthecreaseline.
Thesketchbelow
demonstrateshowthebladealignmentcanbecarriedout.
Adjustmentcanbemadeateitherofthebladeoranvil.Thetwoclearanceholes
positionedabovetherollertiltmechanismarethefrontalignment(oneforblade,onefor
anvil).Thetwoholesarerepeatedonthebackofthemachineforthebackalignment.
1.RemovethestackerunitfromtheDigifold.
2.Usinga3mmallenkey,loosenthecapheadtypelockingscrewslocatedonthe
frontfaceatboth endsoftheblade/anvilasshownbelow.
3.Usinga4mmallenkey,locatethetwofrontorbackalignmentscrewsintheside
frameinordertoadjusttheblade/anvil.
4.Theupperscrewofthetwo,willadjusttheupperblade/anvilwhereasthe
lowerscrewwilladjustthelowerblade/anvilbothinverysmallincrements.
5.Inordertoobtaintherequiredposition,adjusteitherthebladeortheanvilbya
smallamountandthenoperatethemachinetotesttheformofthecrease.
Repeattheexerciseuntilcentralisationislocated.
6.Usinga3mmallenkey,lockthecapheadtypescrews(asperstep3)onboththe
upperandlowerblade/anvil.
Pleasenotethattoavoiddamagetothe
bladeset,adjustmentshouldonlybemadeinsmallincrements.
Page26
CREASING/FOLDING
