Motec Systems C125 User Manual

MoTeC Installation 25
Connecting Devices Examples
Device
Connect via
Remarks
Sensors
Inputs:
The appropriate input
type depends on the
sensor type
MoTeC supplies datasheets
with wiring details for all
sensors via the website
External Buttons for:
- Display mode
- Display next line
(and optional
previous line)
- Alarm acknowledge
- Lap number reset
Inputs:
Digital or Speed inputs
Wire between Display
Logger input and Display
Logger 0 V.
If wired to an Analogue
Voltage input, connect an
external pull-up resistor
between the input pin and
the 5 V sensor supply.
External LED Lights
Outputs:
Auxiliary output
Wire between one of the
Auxiliary Outputs and b
attery
positive and include a
current limiting resistor.
SLM Shift Light
Module
Communications:
CAN
K-type
Thermocouples
Inputs:
Analogue Voltage or
Analogue Temperature
input
Connect via TCA (Thermo
Couple Amplifier)
Communications:
CAN
Connect via E888
ECU M4, M48, M8
Communications:
RS232
Uses the Telemetry feature
of the ECU to send data to
the Display Logger
ECU M84, 'Hundred
Series': M400, M600,
M800, M880
Communications:
CAN
Ensure the ECU and Display
Logger are connected on the
same CAN bus
