Motec Systems C125 User Manual

66 Appendices MoTeC
C125 Pin List by Pin Number
Pin
Name
Function
1
E-TX-
Ethernet Transmit -
2
E-TX+
Ethernet Transmit +
3
AV1
Analogue Voltage Input 1
4
AV2
Analogue Voltage Input 2
5
AV3
Analogue Voltage Input 3
6
AV4
Analogue Voltage Input 4
7
8V
Sensor 8 V
8
5V
Sensor 5 V
9
0v
Sensor 0 V Analogue Volt & Analogue Temp
10
E-RX-
Ethernet Receive -
11
E-RX+
Ethernet Receive +
12
AV5
Analogue Voltage Input 5
13
AV6
Analogue Voltage Input 6
14
DIG1
Digital Input 1
15
DIG2
Digital Input 2
16
AT1
Analogue Temp Input 1
17
AT2
Analogue Temp Input 2
18
CAN1L
CAN1 Lo
19
CAN1H
CAN1 Hi
20
RS232-1 TX
RS232-1 Transmit Output
21
SPD1
Speed Input 1
22
SPD2
Speed Input 2
23
SPD3
Speed Input 3
24
N/C
25
RS232-2 RX
RS232-2 Receive Input
26
CAN2L
CAN2 Lo / RS232 Ground Input
27
CAN2H
CAN2 Hi / RS232 Receive Input
28
RS232-1 RX
RS232-1 Receive Input
29
AUX1
Auxiliary Output 1
30
AUX2
Auxiliary Output 2
31
AUX3
Auxiliary Output 3
32
AUX4
Auxiliary Output 4
33
BAT+
Battery Positive
34
BAT-
Battery Negative
