MoTeC Appendices 57
Appendices
Specifications
Specifications listed as optional are available as upgrades to customise and
grow your system. These additional features are activated through a simple
password system, at any time when you need it.
An overview of the upgrades can be found in
Display Logger Upgrades.
Logging
Optional 120 MB logging memory
Logging rates up to 500 samples per second
Fast Ethernet download
Includes i2 Standard data analysis software
Display
Type: Colour TFT LCD, anti-reflective
Resolution: 800 x 480, anti-aliased graphics
Layouts: selectable fixed layouts, user programmable layouts available in
future releases.
48 user-defined, scrollable message lines with programmable overrides
3 programmable modes with customisable labels
Inputs – (requires 12 I/O Upgrade Option)
6 x Analogue voltage inputs
4 x 0 to 5.46 V, 1.33 mV resolution
2 x 0 to 15.0 V, 3.66 mV resolution
2 x Analogue temperature inputs
2 x 0 to 15 V, 3.66 mV resolution
2 x Digital inputs (provided, does not require 12 I/O Upgrade)
3 x Speed inputs (provided, does not require 12 I/O Upgrade)
Outputs – (requires 12 I/O Upgrade Option)
4 low side outputs PWM or switched operation
Expanders
Compatible with up to two E888 and E816 expanders (with full I/O use)
