8 Introduction MoTeC
Compatibility
• MoTeC ECUs: M4, M48, M8, M84, M400, M600, M800 and M880
• MoTeC accessories: E816, E888, SLM, PLM, LTC, BR2, PDM, GPS,
PDM, etc.
• Many non-MoTeC ECUs and other devices
Required Accessories
See to Connecting the Display Logger to a PC.
• #61225 Network Cable RJ45 1.5 Metre, or other standard ethernet cable
Optional Kits and Accessories
• Any one of the following:
o 18031 Race Display Kit
o 18032 Race Logging Kit
• 62204 C125 Race Loom Terminated
• 61259 C125 Input Loom
• 61197 OBD-II To Display Loom
• 61198 CAN ECU To Display Loom
• 61199 RS232 ECU To Display Loom
• 41304 GPS L10 10Hz
• 61221 Two Button Loom
System Overview
The Display Logger offers extensive possibilities to integrate with ECUs,
peripheral devices and accessories to form a complete solution that powers,
controls, logs, monitors and communicates virtually any automotive
parameter.
Typical devices used with the Display Logger
ECUs
The C125 Display Logger can be connected to all MoTeC engine
management systems and some other manufacturers' ECUs either via CAN,
RS232 or OBD-II. This avoids duplication of sensors and allows the Display
Logger to display and log many ECU parameters.
The typical update rate is about 20 times per second for RS232 and 50 times
per second for CAN, but is less from OBD-II.
