MoTeC Configuration 47
Alarm Displays
When an alarm is activated, a message is shown along the bottom of the
display until it is acknowledged. To draw the driver's attention to the display, it
is recommended to activate a warning light.
The message can be defined as required and can include the current sensor
reading or the sensor reading when the alarm was triggered.
Example active unacknowledged alarm
See the Alarms section for details on behaviour and operation of alarms.
Up to 6 active acknowledged alarms can be displayed in the Alarm Status
Panel along the bottom of the display, covering what was there before. By
default, the Alarm Status Panel display is OFF. This can be set ON by the
user. See Alarms for details about the Alarm Status Panel and its operation.
Below are examples of how active acknowledged alarms would be arranged.
