5. Change the illumination between Halogen and LED
y Attention:
Unplug the plug-in power unit from the power outlet to protect user from electric shock and allow for
a sufficient cool-down time of the6V 30W halogen lamp before you replace it.
y Press down lightly and rotate counter clockwise and remove lamphouse cover. (Fig.21)
(Fig.21)
y Remove the bulb from the socket pinholes.
Halogen bulb (Fig.22) LED (Fig.23)
y Installing the new bulb into the socket pinholes, until it reaches the limited, be careful not to tilt it
when mounting.
y If installing the halogen bulb, do not touch the glass surface of the lamp with bare fingers. Doing so
will cause fingerprints, grease, etc., to burn onto the lamp surface, reducing the illumination
provided by the bulb. If surface is contaminated, wipe it clean using lens or soft cotton.
y Return lamphouse cover to original position and rotate clockwise to lock into place. The white paint
marked on the cover should face the user.
y The same halogen bulb holder can be used for both LED illumination module.
