3. Technical data
Technical data AE2000 AE2000 TRI AE2000 Ergo
Optical system Color-corrected infinity optics
Total Magnification 40X - 400X
Eyepiece tubes
360° rotatable Siedentopf with upper and lower position: upper position
offers approx. 40 mm extra viewing height
Interpupillary distance: 48 mm to 75 mm
Binocular 45° incline Trinocular 45°incline Ergo incline: 45°± 15°
Eyepiece N-WF 10X(ø20), wide field, high eye point
Nosepiece 4x, inclined backwards
Stage
Fixed, Dimensions (width x depth): 200 x 239mm
Stage height 192mm
Object guide
Verniers with numerical and alphabetic scale
X direction: numerical scale, readable from right to left
Y direction: alphabetic scale
Objectives
Plan-Achromat 4x, N.A. 0.1, W.D. 12.6mm
Plan-Achromat 10x, N.A. 0.25, W.D. 16.8mm
LWD Plan-Achromat 20x, N.A. 0.3, W.D. 4.7mm
LWD Plan-Achromat 40x, N.A. 0.5, W.D. 3mm
Plan-Achromat PH 4x Ph0, N.A. 0.1, W.D. 12.6mm
Plan-Achromat PH 10x Ph1, N.A. 0.25, W.D. 4.1mm
LWD Plan-Achromat PH 20x Ph2, N.A. 0.3, W.D. 4.7mm
LWD Plan-Achromat PH 40x Ph2, N.A. 0.5, W.D. 3mm
Condenser
N.A. 0.3, W.D. 72mm
N.A. 0.4, W.D. 53mm
N.A. 0.5, W.D. 28mm
Coarse drive 42mm/rev.
Fine drive 0.2mm/rev.
Transmitted
illumination
6V/30W Halogen
3W LED
Dimension: W x D x H 217.5 x 556 x 497mm
