Troubleshooting Tables: List of Board and IC Signals 7-5
none AVR_STATUS_1.8 J4001-29 P2001-29 AVR_STATUS_1.8V none
OMAP_RE
SET_TP
OMAP_RESET J4001-30 P2001-30 OMAP_RESET_OUT none
C6544 VBUS1 J4001-31 P2001-31 VBUS1 none
none MACE_RESET J4001-32 P2001-32 MACE_RESET none
R6623 USB1_NEG_DP J4001-33 P2001-33 USB1_DM none
none MACE_WAKEUP J4001-34 P2001-34 MACE_WAKEUP TP2502
R6622 USB1_POS_DP J4001-35 P2001-35 USB1_DP none
none TX_INHIBIT J4001-36 P2001-36 TX_INHIBIT none
none EXP_BRD_ID J4001-37 P2001-37 EXP_BRD_TYPE R2021
none KEYFAIL J4001-38 P2001-38 KEYFAIL R2501
chassis GND J4001-39 P2001-39 GND chassis
none SECURE_HIGH_NORM J4001-40 P2001-40 MACE_SEC_CLR_MODE none
C6561 V_SW_3.60 J4001-41 P2001-41 VSW_3.6 TP2007
chassis GND J4001-42 P2001-42 GND chassis
none AVR_BOOT J4001-43 P2001-43 USB_BOOT_1.8V TP2417
R6107 SSI_OPT_CLK J4001-44 P2001-44 OPT_SSI_CLK R2503
C6405 V_2.775_EXP J4001-45 P2001-45 VCC_2.775 TP2011
none OPT_SSI_SYNC J4001-46 P2001-46 OPT_SSI_FSYNC R2513
chassis GND J4001-47 P2001-47 GND chassis
R6103 SSI_BLACK_RX J4001-48 P2001-48 SSI_BLACK_RX none
C6567 V_SW_5 J4001-49 P2001-49 VSW_5.4 TP2006
none SSI_BLACK_TX_MACE J4001-50 P2001-50 SSI_BLACK_TX_MACE none
C6567 V_SW_5 J4001-51 P2001-51 VSW_5.4 TP2006
R6102 HIGH_SECURE_DATA_GATE J4001-52 P2001-52 BLOCK_SSI_RED none
chassis GND J4001-53 P2001-53 GND chassis
none SSI_RED_RX_MACE J4001-54 P2001-54 SSI_RED_RX_MACE none
R6525 EMERG_BTN J4001-55 P2001-55 EMERG_BTN none
none SSI_MACE_TX_DIN J4001-56 P2001-56 SSI_MACE_TX_DIN none
R4005 PTT J4001-57 P2001-57 CONN_INT_PTT D2007
Table 7-3. VOCON board to EXPANSION board connector Interface PIN-OUT (Continued)
VOCON Board Expansion Board
Test
Place
signal name pin # pin # signal name
Test
Place
