Motorola APX 6000 Service Manual

7-6 Troubleshooting Tables: List of Board and IC Signals
chassis GND J4001-58 P2001-58 GND chassis
R4007 SIDE_2 J4001-59 P2001-59 CONN_SB2 C2013
R6113 4MHZ_MACE_CLK J4001-60 P2001-60 MACE_CLOCK none
R4006 SIDE_1 J4001-61 P2001-61 CONN_SB1 C2016
chassis GND J4001-62 P2001-62 GND chassis
D6101 MONITOR J4001-63 P2001-63 MONITOR C2014
C6538 V_SAVE J4001-64 P2001-64 VSAVE D2521
none GPIO_4_CTS_KEYFAIL_FILLCLK J4001-65 P2001-65 GCAI_GPIO4_CTS R2005
C6590 VRTC J4001-66 P2001-66 VRTC C2527
D4001 GPIO_0 J4001-67 P2001-67 GCAI_GPIO0 R2004
none EXT_MIC_NEG_DP J4001-68 P2001-68 GCAI_EXT_MIC_N none
chassis GND J4001-69 P2001-69 GND chassis
R6404 EXT_MIC_POS_DP J4001-70 P2001-70 GCAI_EXT_MIC_P L2002
F_GCAI_U
SB+
GPIO_1_DP_TXDC_FILLREQ J4001-71 P2001-71 GCAI_USB_P_GPIO1 VR2002
SPKR- EXT_SPKR_NEG_DP J4001-72 P2001-72 GCAI_EXT_SPKR_N VR2006
F_GCAI_U
SB
GPIO_2_DM_RXDC_FILLDATA J4001-73 P2001-73 GCAI_USB_N_GPIO2 VR2003
SPKR+ EXT_SPKR_POS_DP J4001-74 P2001-74 GCAI_EXT_SPKR_P VR2005
chassis GND J4001-75 P2001-75 GND chassis
chassis GND J4001-76 P2001-76 GND chassis
F_V1BUS2 VBUS2 J4001-77 P2001-77 GCAI_VBUS_5V D2002
none GPIO_3_RTS_FILLSENSE J4001-78 P2001-78 GCAI_RTS_GPIO3 D2009
F_V1BUS2 VBUS2 J4001-79 P2001-79 GCAI_VBUS_5V D2002
F_GCAI_1
WIRE
GCAI_1WIRE_5V J4001-80 P2001-80 GCAI_ONE_WIRE D2001
Table 7-3. VOCON board to EXPANSION board connector Interface PIN-OUT (Continued)
VOCON Board Expansion Board
Test
Place
signal name pin # pin # signal name
Test
Place
