Motorola APX 6000 Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2 8-79
R812 0613952Q47 CER CHIP RES 82.0 OHM 5%
0402
R813 0613952Q69 CER CHIP RES 680 OHM 5 0403
R815 0613952Q34 CER CHIP RES 24.0 OHM 5
0402
R818 0613952Q23 CER CHIP RES 8.2 OHM 5 0402
R819 0613952Q59 CER CHIP RES 270 OHM 5 0402
R822 0613952R08 CER CHIP RES 20K OHM 5 0402
R823 0613952R19 CER CHIP RES 56K OHM 5%
0402
R827 0613952Q92 CER CHIP RES 6200 OHM 5
0402
R832 0613952Q29 CER CHIP RES 15.0 OHM 5
0402
R833 0613952Q49 CER CHIP RES 100 OHM 5 0409
R840 0613952Q29 CER CHIP RES 15.0 OHM 5
0402
R848 0613952Q29 CER CHIP RES 15.0 OHM 5
0402
R849 0613952Q67 CER CHIP RES 560 OHM 5 0402
R1102 0613952R25 CER CHIP RES 100K OHM 5%
0402
R1103 6009259001 LOW RESISTANCE THICK FILM
RESI
R1104 0613952Q49 CER CHIP RES 100 OHM 5 0402
R1105 0613952Q49 CER CHIP RES 100 OHM 5 0403
R1106 0613952Q21 CER CHIP RES 6.8 OHM 5 0402
R1107 0613952Q45 CER CHIP RES 68.0 OHM 5
0402
R1108 0613952R23 CER CHIP RES 82K OHM 5%
0402
R1110 0613952R01 CER CHIP RES 10K OHM 5%
0404
R1112 NOT PLACED –
R1114 0613952Q49 CER CHIP RES 100 OHM 5 0404
R1115 0613952Q49 CER CHIP RES 100 OHM 5 0405
R1116 0613952R01 CER CHIP RES 10K OHM 5%
0405
R1117 0613952R22 CER CHIP RES 75K OHM 5 0402
R1121 0613952R12 CER CHIP RES 30K OHM 5 0402
R1122 0613952R22 CER CHIP RES 75K OHM 5 0402
Ref.
Des.
Part Number Description
R1124 0613952Q42 CER CHIP RES 51.0 OHM 5
0402
R1125 0613952Z58 RES,MF,22KOHM,1%,.0625W,
SM,040
R1126 0613952Z54 RES,MF,9.1KOHM,1%,.0625W,
SM,04
R1127 0613952R09 CER CHIP RES 22K OHM 5%
0402
R1128 0613952R01 CER CHIP RES 10K OHM 5%
0406
R1129 NOT PLACED –
R1130 NOT PLACED –
R1135 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1136 0613952R01 CER CHIP RES 10K OHM 5%
0407
R1137 0613952R01 CER CHIP RES 10K OHM 5%
0408
R1138 0613952R25 CER CHIP RES 100K OHM 5%
0403
R1139 0613952R25 CER CHIP RES 100K OHM 5%
0404
R1140 0613952R25 CER CHIP RES 100K OHM 5%
0405
R1141 0613952R42 CER CHIP RES 510K OHM 5
0402
R1142 0613952R25 CER CHIP RES 100K OHM 5%
0406
R1143 0613952R25 CER CHIP RES 100K OHM 5%
0407
R1144 0613952R25 CER CHIP RES 100K OHM 5%
0408
R1145 0613952R25 CER CHIP RES 100K OHM 5%
0409
R1146 0613952R25 CER CHIP RES 100K OHM 5%
0410
R1151 0613952R05 CER CHIP RES 15K OHM 5%
0402
R1152 0613952R01 CER CHIP RES 10K OHM 5%
0409
R1154 0613952R01 CER CHIP RES 10K OHM 5%
0410
R1158 NOT PLACED –
R1160 0613952R03 CER CHIP RES 12K OHM 5%
0402
Ref.
Des.
Part Number Description
R1162 0613952R29 CER CHIP RES 150K OHM 5%
0402
R1163 0613952R01 CER CHIP RES 10K OHM 5%
0411
R1164 0613952R01 CER CHIP RES 10K OHM 5%
0411
R1165 0613952Q56 CER CHIP RES 200 OHM 5 0402
R1166 0613952Q56 CER CHIP RES 200 OHM 5 0402
R1167 0613952R01 CER CHIP RES 10K OHM 5%
0412
R1168 0613952Q49 CER CHIP RES 100 OHM 5 0406
R1169 0613952P52 CER CHIP RES 340K OHM 1
0402
R1170 0613952P01 CER CHIP RES 100K OHM 1
0402
R1171 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1172 0613952Q89 CER CHIP RES 4700 OHM 5
0402
R1174 0613952R01 CER CHIP RES 10K OHM 5%
0413
R1175 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1176 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R1177 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1178 0613952R01 CER CHIP RES 10K OHM 5%
0414
R1180 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1181 NOT PLACED –
R1182 0613952R01 CER CHIP RES 10K OHM 5%
0415
R1183 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R1184 0613952Q81 CER CHIP RES 2200 OHM 5
0402
R1186 NOT PLACED –
R1304 NOT PLACED –
R1307 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R1500 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Ref.
Des.
Part Number Description
R1501 NOT PLACED –
R1502 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R1503 0613952R08 CER CHIP RES 20K OHM 5 0402
R1504 0613952R13 CER CHIP RES 33K OHM 5%
0402
R1505 0613952R01 CER CHIP RES 10K OHM 5%
0416
R1506 0613952R03 CER CHIP RES 12K OHM 5%
0402
R2001 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2002 NOT PLACED –
R2006 0613952R01 CER CHIP RES 10K OHM 5%
0417
R2007 0613952R01 CER CHIP RES 10K OHM 5%
0418
R2008 0613952R01 CER CHIP RES 10K OHM 5%
0419
R2009 0613952R01 CER CHIP RES 10K OHM 5%
0420
R2010 0613952Q96 CER CHIP RES 9100 OHM 5
0402
R2011 0613952Q96 CER CHIP RES 9100 OHM 5
0403
R2021 0613952R22 CER CHIP RES 75K OHM 5 0402
R2022 0613952R27 CER CHIP RES 120K OHM 5%
0402
R2023 0613952R01 CER CHIP RES 10K OHM 5%
0421
R2024 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R2025 0613952Q11 CER CHIP RES 2.7 OHM 5 0402
R2035 0613952Q75 CER CHIP RES 1200 OHM 5
0402
SH1 26009322001 SHIELD, RF PA
SH2 2675872B01 SHIELD, XTAL
SH3 2675873B01 SHIELD, ABACUS
SH4 26009323001 SHIELD, DC FILTER
SH5 26009327001 SHIELD, OUTPUT MATCH
SH6 26009320001 SHIELD, ALC
SH7 2675874B01 SHIELD, MIXER
SH8 2675932B01 SHIELD, 2ND LO VCO
Ref.
Des.
Part Number Description
