Motorola APX 6000 Service Manual

8-80 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2
SH9 26009319001 SHIELD, VCO
SH10 26009324001 SHIELD, HARMONIC FILTER
SH11 26009321001 SHIELD, RX FRONT END
SH12 2675933B01 SHIELD, IF AMP
SH13 26009325001 SHIELD, FGU
SH14 26009326001 SHIELD, DC REGULATOR
T503 2575851B01 RF TRANSFORMER BALUN
T504 2575851B01 RF TRANSFORMER BALUN
T505 2575851B01 RF TRANSFORMER BALUN
U101 5105443X07 EEPROM 32KBIT SERIAL SPI
BUS
U200 5188493T01 IC,VREG/SWG,LP2989,SM,MINI
SO-
U201 5175771A99 LOW NOISE, 100MA LINEAR
REGULA
U202 5175772B02 LINEAR REGULATOR 100MA
1.8V
U203 5175772B01 LINEAR VOLTAGE REGULATOR
350MA
U506 5164852H82 IC, MIXER/ BUFFER
U601 5102495J14 IC,IF,IF DIGITILIZING SUBSYST
U602 4885316E38 TRANSISTOR, RF
U603 5109522E84 IC DUAL SCHMITT TRIG MICRO
PAK
U604 5109522E84 IC DUAL SCHMITT TRIG MICRO
PAK
U605 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLA
U606 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLA
U607 5186311J24 IC,BFR,1BITS,NC7SZ125,ACTIV
E H
U702 5164015H28 IC,TRIDENT,INTEG SYNTH,
RX/TX B
U703 5175772B06 28-PORT I/O EXPANDER
U709 5171972L01 SP3T RF SWITCH
U710 5171972L01 SP3T RF SWITCH
U746 4805218N63 RF TRANS SOT 323 BFQ67W
U1101 5188032U43 IC,SENSING
CIRCUIT,INA138,SM,S
U1102 5175772B03 RECONFIGURABLE 10W SP5T/
3T RF
Ref.
Des.
Part Number Description
U1103 5185070Y01 IC TEMPERATURE SENSOR
PB-FREE
U1104 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1105 5180390L83 IC,CNTLR,SM,1PER PKG
U1106 5175772B05 PRECISION RF DETECTOR
U1111 5175771A26 CMOS FET SWITCH SPDT,
10WATTS
U1112 5175772B04 1 DB LSB GAAS MMIC
ATTE NUATOR
U1113 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1114 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1116 5109522E93 2 INPUT OR GATE IN NANO
PACKAG
U1117 5103535B53 IC,INVTR,DL,NC7WZ04L6X,
2PER PK
U1118 5109522E93 2 INPUT OR GATE IN NANO
PACKAG
U1119 5109522E94 2 INPUT AND GATE IN NANO
PACK A
U1121 5114000B52 IC,XOR,LOGIC LEVEL
SHIFTER,1PE
U1125 51009382001 IC, QUAD DAC
U1126 5109817F77 IC COMPTR LM7275 5SC70
(D54)
U1127 5171779H01 SPDT ANALOG SWITCH
U1128 5188085K11 IC, SINGLE NAND GATE, 2-
INPUT,
U1129 5175143H01 WIDE SUPPLY RANGE OP AMP
U1130 5175143H01 WIDE SUPPLY RANGE OP AMP
U1131 5109817F77 IC COMPTR LM7275 5SC70
(D54)
U1132 5114007M28 IC,F-F/D,1PER PKG,17SZ74,N-I,
S
U1133 5171779H01 SPDT ANALOG SWITCH
U1136 5109522E94 2 INPUT AND GATE IN NANO
PACK A
U1137 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLA
U1138 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLA
Ref.
Des.
Part Number Description
U1139 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLA
U1141 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1142 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1143 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1144 5171779H01 SPDT ANALOG SWITCH
U1146 5109522E93 2 INPUT OR GATE IN NANO
PACKAG
U1147 5109522E94 2 INPUT AND GATE IN NANO
PACK A
U1148 5185941F56 IC SINGLE LV LP OP
AMPLIFIER
U1149 5185941F45 ATTEN,VAR,14.4DBMIN,15.6DB
MAX,
U1150 51009381001 LOW DROPOUT VOLTAGE
REFERENCE
U1304 5105739X13 IC, SIGE GPS LOW NOISE AMP
157
U1500 51012101001 VHF/UHF/800/900 MHZ LDMOS
DRIV
U1501 5175143H01 WIDE SUPPLY RANGE OP AMP
U2032 4885316E38 TRANSISTOR, RF
VR101 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,2
VR200 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,2
VR601 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-
VR602 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-
VR2005 4815096H01 VARACTOR DIODE 1SV305
VR2006 4815096H01 VARACTOR DIODE 1SV305
VR2007 4815096H01 VARACTOR DIODE 1SV305
VR2008 4815096H01 VARACTOR DIODE 1SV305
VR2010 4815096H01 VARACTOR DIODE 1SV305
VR2020 4815096H01 VARACTOR DIODE 1SV305
Y701 4871886H01 16.8 MHZ VCTXO .8PPM
Y704 5164852H68 IC, VCO MODULE
Y705 5164852H66 IC, VCO MODULE
Ref.
Des.
Part Number Description
