Motorola APX 6000 Service Manual

Schematics, Boards Overlays, and Parts Lists: Expansion Board 8-169
R2311 0613952R18 CER CHIP RES 51K OHM 5
0402
R2312 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2313 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2401 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R2402 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2403 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2404 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2405 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2407 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2408 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2409 0613952Q50 CER CHIP RES 110 OHM 5 0402
R2410 0613952Q43 CER CHIP RES 56.0 OHM 5
0402
R2411 0613952Q50 CER CHIP RES 110 OHM 5 0402
R2412 0613952Q53 CER CHIP RES 150 OHM 5
0402
R2413 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2414 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2415 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2416 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2417 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2419 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2420 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2421 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Ref.
Des.
Part Number Description
R2422 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2423 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2424 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2425 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2426 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2427 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2428 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2429 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2430 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2431 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2432 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2433 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2434 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2435 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2436 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2437 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2438 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2440 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2441 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2442 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R2443 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R2444 0613952R25 CER CHIP RES 100K OHM 5%
0402
Ref.
Des.
Part Number Description
R2449 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2450 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2451 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2452 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2453 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2454 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2455 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2456 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2457 0613952R05 CER CHIP RES 15K OHM 5%
0402
R2458 0613952Q89 CER CHIP RES 4700 OHM 5
0402
R2459 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2460 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2461 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2462 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2465 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2466 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2467 0613952Q32 CER CHIP RES 20.0 OHM 5
0402
R2469 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R2472 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2473 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2474 0613952R35 CER CHIP RES 270K OHM 5%
0402
R2475 0613952Q53 CER CHIP RES 150 OHM 5
0402
Ref.
Des.
Part Number Description
R2476 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2477 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2478 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2479 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2480 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2481 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2484 0613952Q39 CER CHIP RES 39.0 OHM 5
0402
R2485 0613952Q39 CER CHIP RES 39.0 OHM 5
0402
R2486 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2487 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2488 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2489 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2490 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2491 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2492 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2493 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2495 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2496 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2497 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2501 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2505 0613952Q75 CER CHIP RES 1200 OHM 5
0402
R2507 0613952R49 CER CHIP RES 1.0M OHM 5%
0402
Ref.
Des.
Part Number Description
