Motorola APX 6000 Service Manual

8-170 Schematics, Boards Overlays, and Parts Lists: Expansion Board
R2508 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2509 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2511 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2512 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2513 0613952Q80 CER CHIP RES 2000 OHM 5
0402
R2516 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2517 0613952R01 CER CHIP RES 10K OHM 5%
0402
R2519 0613952H25 CER CHIP RES 10.0 OHM 5%
0603
R2522 0613952R74 RES,MF,10MOHM,5%,.0625W,
SM,0402,400PPM/CEL,PB-
FREE
R2523 0613952R74 RES,MF,10MOHM,5%,.0625W,
SM,0402,400PPM/CEL,PB-
FREE
R2524 0613952R49 CER CHIP RES 1.0M OHM 5%
0402
R2529 0613952P30 CER CHIP RES 200K OHM 1
0402
R2530 0613952P30 CER CHIP RES 200K OHM 1
0402
SH1 26009331001 SHIELD, GPS BLUETOOTH
SH2 26009333001 SHIELD, AUDIO AMPLIFIER
SH3 26009334001 SHIELD, MACE MMC
SH4 26009332001 SHIELD, AVR MEMORY
U2101 5187605U22 IC,AU AMP,1PER PKG,SM,PB-
FREE
U2104 5175772B38 IC ANALOG TEMPERATURE
SENSOR
U2301 51009573001 IC,FLASH,MMC,NAND,4
GB,FBGA
U2401 51007377001 IC, XCVR, BLUETOOTH, GPS,
FM RX, FM TX
U2402 51002923001 IC,LNR V REGLTR,3.3V LP2989,
NOPB
U2403 51009371001 RFID WAKEUP RECEIVER
U2404 5105739X13 IC, SIGE GPS LOW NOISE AMP
1575 MHZ
Ref.
Des.
Part Number Description
U2405 5187344N09 LOW NOISE, 100MA LINEAR
REGULATOR 2.8V
U2406 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2407 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2408 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2409 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2410 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2411 5175856M01 DUAL INVERTER
U2412 5114007M45 IC,NOR,1PER PKG,SOT-353,
PB-FREE
U2413 51009373001 IC SDRAM MEMORY
MT48LC8M16LFB4
U2414 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2415 51009372001 IC MICROCONTROLLER
AT32UC3A0512
U2416 51009669001 IC, ACCELEROMETER,
MOTION SENSOR
U2473 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2478 5164852H16 IC TRANSCEIVER W/LEVEL
TRANSLATION
U2510 5185912Y03 IC,CRYPTOGRAPHIC
PROCESSOR
U2525 5171339H01 MICROPOWER VOLTAGE
REGULATOR
U2526 5171988H01 CMOS COMPARATOR
VR2001 4805656W94 ZENER DIODE ESD
SUPPRESSOR
VR2004 4805656W94 ZENER DIODE ESD
SUPPRESSOR
VR2005 4805656W94 ZENER DIODE ESD
SUPPRESSOR
VR2006 4805656W94 ZENER DIODE ESD
SUPPRESSOR
Y2204 93009290001 26 MHZ TCXO
Y2475 48009319001 SMD CRYSTAL OSCILLATOR
DS0211AR
Ref.
Des.
Part Number Description

Motorola APX 6000 Specifications

General

Frequency Range	700/800 MHz, VHF, UHF Range 1, UHF Range 2
IP Rating	IP67
P25 Phase 1 & 2	Yes
GPS	Yes
Encryption	AES, DES
Power Output	1-3 Watts (700/800 MHz)
Operating Temperature	-30°C to +60°C
Intrinsically Safe	Yes
Bluetooth	Yes (Bluetooth 4.0)
