Motorola ASTRO Digital XTL 5000 User Manual

October 27, 2004 9964416H03-O
4-2 Troubleshooting: Power-Up Errors
See the ASTRO Digital XTL 5000 Mobile Radio Basic Service Manual for all other error codes.
FAIL 22 or 02/90 General DSP Hardware Failure FATAL Turn the radio off, then on.
FAIL 21/90 Multiple Primary or Auxiliary Radios -
This can be caused by both radios
being programmed as Primary or
both radios being programmed as
Auxiliary.
FATAL Reconfigure the codeplugs so that
one radio is set as Primary, and
one is set as Auxiliary.
ERROR 29 or 09/10 Secure Hardware Failure NON-FATAL Replace the secure module
FAIL 29 or 09/90 Secure Hardware Fatal Error FATAL Replace the secure module
FL 21 or 01/A0 Abacus IC Failure FATAL Turn the radio off, then on.
FL 22 or 02/C0 Wrong Microprocessor FATAL Send the radio to the depot;
Replace the daughter card.
Note: 01, 02, or 09 denotes a failure on the Primary Radio. 21, 22, or 29 denotes a failure on the Auxiliary Radio.
Table 4-1. XTL 5000 Dual-Radio Power-Up Self-Check Error Codes (Continued)
Error Code Description Error Type Troubleshooting Chart

Motorola ASTRO Digital XTL 5000 Specifications

General

Brand	Motorola
Model	ASTRO Digital XTL 5000
Category	Radio
Language	English
