Motorola ASTRO Digital XTL 5000 User Manual

9964416H03-O October 27, 2004
Chapter 1 Introduction
1.1 General
A typical ASTRO Digital XTL 5000 Dual-Radio W3 Handheld Control Head (HHCH) System consists
of two XTL 5000 mobile radios (in different frequency bands), a single W3 HHCH, an interconnect
cable with a quick-disconnect adaptor for the HHCH, and two speakers.
When equipped, typical features such as Scan, Secure, DTMF Hot Keypad, Volume Control, Radio
Selection, Push-To-Talk, and Monitor will be accessible through the HHCH.
1.1.1 Dual-Radio Software
The dual-radio option is supported by mobile host firmware release 6.5 or greater and ASTRO 25
Mobile CPS release R05.00.00 or greater.
1.1.2 Accessory Support
The dual-radio system supports the use of a Motorola Siren/PA. Refer to Section 2.3.13, "Siren/
PA," on page 2-6 for details on the Siren/PA operation in a dual-radio system.
The dual-radio system supports the use of an Emergency Footswitch. Refer to Section 2.3.6,
"Emergency Operation," on page 2-4 for details on how Emergency is handled in a dual-radio
system.
The dual-radio system does NOT support the use of a VRS.
1.2 Ordering Information
The dual-radio option is not available for field upgrades. FLASHport
®
does not support the dual-radio
option. As a result, all mobile radios in the dual-radio system must be ordered from the factory with
the dual-radio option(s).
The unique orderable options of the dual-radio system are as follows:
Table 1-1. Dual-Radio Options
Item Number Description Quantity
G72AASP W3 HHCH with Quick Disconnect One per dual-radio system required.
W845BA Dual-Radio Cable Kit for W3 One per dual-radio system required.
G474AB Multi-Radio Software Two per dual-radio system required. Each
mobile must be equipped with this option
in order to function within the dual-radio
system.
