June 3, 2005 6815851H01-O
2-2 Standard Configurations: Planning the Installation
2.1.1 Installation Examples
Your mobile two-way radio offers only dash mount installation. (see Figure 2-1 through Figure 2-3).
Figure 2-1. Mounting Flexibility in Middle Console Figure 2-2. On Top or Under Dash Mounting
Figure 2-3. In Dash Mounting
Radio
Antenna
1/4-Wavelength
Battery
Speaker
(optional)
Radio
Antenna
1/4-Wavelength
Battery
Speaker
(optional)
Radio
Radio
Antenna
1/4-Wavelength
Battery
Speaker
(optional)
