6815851H01-O June 3, 2005
Standard Configurations: Microphone Hang-Up Clip 2-11
2.6 Microphone Hang-Up Clip
2.6.1 Standard Hang-Up Clip
The hang-up clip must be within reach of the operator(s). Measure this distance before actually
mounting the bracket. Since the bracket has a positive-detent action, the microphone can be
mounted in any position. The microphone hang-up clip must be grounded.
Use the hang-up clip as a template to locate the mounting holes. To avoid interference when
removing the microphone, install the flathead screw in the top clip hole.
2.6.2 Handheld Hang-Up Box
Use the hang-up box (HUB) as a template to locate the mounting holes. Be sure the HUB will be
within easy reach of the operator. Open the accessory cable connector and connect the HUB control
wire to location 3 of the accessory connector. Connect the other control wire from the HUB to a
convenient solid chassis ground point.
2.7 Completing the Installation
Complete the installation by connecting the power wires and plugging in the microphone cable. Be
sure to connect the microphone S-hook to the holes in the trunnion provided (see Figure 2-7) for
strain relief.
