June 3, 2005 6815851H01-O
3-8 Options and Accessories Installation: Accessory Connector Assembly Details (P2)
5. Squeeze the covers together bending the wires in the strain-relief features. You may need a
pair of pliers to seat the assembly covers.
6. Once the covers are fully seated, fasten them with the cover screws. Tighten the screws
firmly but do not over-tighten them. Be sure none of the wires are pinched.
7. Reattach the accessory connector assembly to the back of the radio and fasten it by finger-
tightening the jackscrews to prevent any loosening.
