Motorola MT512M Basic Service Manual

MODEL INFORMATION & ACCESSORIES 2 - 1
CHAPTER 2
MODEL INFORMATION & ACCESSORIES
MTM800 with Enhanced Control Head Mobile Terminal
Model Information
This manual applies to the following Mobile Terminal Models
Sales Model Nomenclature
Type No. Sales Model No. Short Description Model
MT512M
MT912M
M80RCS6TZ5AN
M80PCS6TZ5AN
MTM800 ENH 410
–470 MHz, DASH
MTM800 ENH 380–430 MHz, DASH
M1
MT512M
MT912M
M80RCS6TZ4AN
M80PCS6TZ4AN
MTM800 ENH 410
–470 MHz, DESK
MTM800 ENH 380–430 MHz, DESK
M2
MT512M
MT912M
M80RCS6TZ6AN
M80PCS6TZ6AN
MTM800 ENH 410
–470 MHz, REMOTE
MTM800 ENH 380
–430 MHz, REMOTE
M3
MT512M
MT912M
M80RCS6TZ2AN
M80PCS6TZ2AN
MTM800 ENH 410
–470 MHz, M’CYCLE
MTM800 ENH 380
–430 MHz, M’CYCLE
M4
MT512M
MT912M
M80RCA6TZ5AN
M80PCA6TZ5AN
MTM800 ENH 410–470 MHz, Data
MTM800 ENH 380–430 MHz, Data
M5
Typical Model Number: M 8 0 R C N 6 T Z 5 A N
Position:
2 3
1
4 5 7
10 9
11
12
8 6
Type of Unit
M = Mobile Product
Model Series
80 = MTM800 ENH
Frequency Band
P = 380 - 430 MHz
R = 410 - 470 MHz
U = 806 - 870 MHz
Level
C = 1.0 to 3.9 Watts
Physical Packages
C = Expansion/Data Head
S = Enhanced Control Head
Channel Spacing
6 = 20/25 kHz
Unique Variation
N = Standard Package
Version Letter
Feature Level
5 = Dash/Desk Mount
4 = Desk Mount
2 = Motorcycle Mount
6 = Remote Mount
Primary System Type
Z = TETRA
Primary Operation
T = Trunking
