5.1 - 8 TEST SETUP & TESTING for 380–430 MHz and 410–470 MHz
Configuration of the IFR 2968 Manual Test Screen
The setup depends on the firmware version of the IFR 2968, the firmware version of the
terminal and the customer programming of the terminal. The following procedure is only
an example.
1. To enter “Manual test” screen, press the “Manual” soft key.
2. Press the "Control Channel" soft key. Thereafter, enter the control channel Number
and press the "Control Channel" soft key. The control channel Number for
380
–430MHz is "840" = Rx 421.0125MHz (for 410–470MHz it is "2440" = Rx
461.0125MHz).
3. Press the "Traffic Channel" soft key. Enter "840" for 380
–430MHz ("2440" for
410
–470MHz) and press the "Traffic Channel" soft key. The marker goes to Timeslot.
Enter "3" and press the "Traffic Channel" soft key. (Note that the Traffic Channel
number changes automatically after entering the Control Channel number).
4. Press the “RF Gen Level” soft key. Thereafter, enter “-90” and press “dBm” data keys
followed by “RF Gen Level” soft key.
5. Press the “Mobile Power” soft key, enter “35 dBm/3.2W“, using soft key.
6. Press the “Burst Type” soft key and “Normal” soft key.
7. This completes the Manual test equipment configuration setup.
Note: The System Setup Configuration Data is saved even after the power is turned
off. However, the Manual Test Setup is not saved.
