6 - 20 MAINTENANCE
Motorcycle Mount Enhanced Control Head – Reassembly
1. Fit the rubber keypad onto the Motorcycle Mount Enhanced Control Head front housing and
ensure that the keypad is correctly aligned and pressed onto the groove of the front housing.
2. Assemble the board to the Motorcycle Mount Enhanced Control Head front housing.
3. Assemble the encoder switch flex to the socket on the board.
4. Screw the two 8mm self tapping screws and one 14mm self tapping screw.
5. Assemble the remote PCB into the motorcycle back housing by screwing the 3 screws.
6. Connect the flex from the remote board on the back housing to the connector on the PCB
board of the Motorcycle Mount Enhanced Control Head front housing.
7. Snap the back housing into the Motorcycle Mount Enhanced Control Head front housing.
8. Screw the middle screw to the back housing.
Service Aids
The following table lists the service aids recommended for working on the terminal. While all of
these items are available from Motorola, most are standard workshop equipment items, and any
equivalent item capable of the same performance may be substituted for the item listed.
Table 6-4 Service Aids
Motorola Part No. Description Application
6666500A01 Housing Eliminator Test Fixture used to bench test the terminal
pcb
6686119B01 Dismantling Tool Assists in the removal of terminal Enhanced
Control Head
0180320B16
6680321B81
6680321B56
Torx Screw Driver Kit (T6,8,10,15,25)
Torx Bit
Insert Bit extra long
T-20 TORX
(or equivalent)
Screwdriver with torque meter
To Next Page
