Motorola MT512M Basic Service Manual

A - 6 REPLACEMENT PARTS & KITS
SERVICE KITS
Table 1 Model Numbering Information
Type No. Sales Model No. Short Description Model
MT512M
MT912M
M80RCS6TZ5_N
M80PCS6TZ5_N
MTM800 ENH 410–470 MHz, DASH
MTM800 ENH 380–430 MHz, DASH
M1
MT512M
MT912M
M80RCS6TZ4_N
M80PCS6TZ4_N
MTM800 ENH 410–470 MHz, DESK
MTM800 ENH 380–430 MHz, DESK
M2
MT512M
MT912M
M80RCS6TZ6_N
M80PCS6TZ6_N
MTM800 ENH 410–470 MHz, REMOTE
MTM800 ENH 380–430 MHz, REMOTE
M3
MT512M
MT912M
M80RCS6TZ2_N
M80PCS6TZ2_N
MTM800 ENH 410–470 MHz, M’CYCLE
MTM800 ENH 380–430 MHz, M’CYCLE
M4
MT512M
MT912M
M80RCA6TZ5_N
M80PCA6TZ5_N
MTM800 ENH 410–470 MHz, Data
MTM800 ENH 380–430 MHz, Data
M5
Table 2 Service Kits-To-Model Chart
MTM800 Service Kits
Description Part Number M1 M2 M3 M4 M5
Service Boards 380–430MHz
MTM800 ENH 380–430 CLEAR
1
PMUE4464_S X X X X X
MTM800 ENH 380–430 TEA1
1,2
PMUE4465_S X X X X X
MTM800 ENH 380–430 TEA2
1,2
PMUE4466_S X X X X X
MTM800 ENH 380–430 TEA3
1,2
PMUE4467_S X X X X X
MTM800 ENH 380–430 CLEAR MAINBOARD
1,3
PMUE4464_W X X X X X
MTM800 ENH 380–430 TEA1 MAINBOARD
1,2,3
PMUE4465_W X X X X X
MTM800 ENH 380–430 TEA2 MAINBOARD
1,2,3
PMUE4466_W X X X X X
MTM800 ENH 380–430 TEA3 MAINBOARD
1,2,3
PMUE4467_W X X X X X
MTM800 ENH 380–430 GPS CLEAR
1
PMUE4468_S X X X X X
MTM800 ENH 380–430 GPS TEA1
1,2
PMUE4469_S X X X X X
MTM800 ENH 380–430 GPS TEA2
1,2
PMUE4470_S X X X X X
MTM800 ENH 380–430 GPS TEA3
1,2
PMUE4471_S X X X X X
MTM800 ENH 380 UCM-M AES128
1
PMUE2881_S X X X X X
MTM800 ENH 380 UCM-M TEA1 AES128
1,2
PMUE2882_S X X X X X
MTM800 ENH 380 UCM-M TEA2 AES128
1,2
PMUE2883_S X X X X X
MTM800 ENH 380 UCM-M TEA3 AES128
1,2
PMUE2884_S X X X X X
MTM800 ENH 380 UCM-M GPS AES128
1
PMUE2885_S X X X X X
MTM800 ENH 380 UCM-M GPS TEA1 AES128
1,2
PMUE2886_S X X X X X
