Motorola MTP85 0EX Series Basic Service Manual

GENERAL
Nominal 7.6 Vdc
Portable Dimensions:
(HxWxD in mm)
145.2 x 56.6 x 39.6 mm
Weight:
Full Keypad (FKP) non-SIM 438 ± 2 g
FKP SIM 441 ± 2 g
Limited Keypad (LKP) non-SIM 440 ± 2 g
LKP SIM 442 ± 2 g
Table 10: Receiver Specifications
RECEIVER
Receiver Type: Class A and B
Frequency Range: 350–470 MHz
Channel Spacing: 25 kHz
Sensitivity (3.5%) BER: –116 dBm (guaranteed)
–118 dBm (typical)
Intermodulation: (3.5 %) BER
Interfering Signal Level –47 dBm
Selectivity Blocking:
(50–100 kHz)
(3.5 %) BER
Interfering Signal Level –40 dBm
Spurious Rejection: (3.5 %) BER
Interfering Signal Level –45 dBm
Frequency Stability:
Locked to Base ±100 Hz
Unlocked to Base ±1000 Hz
Audio Rated 1.3 W
Distortion at Rated Audio: 15 % Max.
Table 11: Transmitter Specifications
TRANSMITTER
Modulation Type: π/4DQPSK
RF Power: Class 3L
Class 4
Frequency Range:
TMO 350–470 MHz
MN002465A01-AN
Chapter 1 : Model Information
23
