Motorola MTP85 0EX Series Basic Service Manual

Figure 9: Back Cover Identification Kit Removal
2
3
1
1
Annotation Description
1 Left or right side
2 Back cover identification kit
3 Back chassis
5.5.2.5
Removing the Back Cover Lens and Identification Tag
Procedure:
Slide the back cover lens upwards to remove the back cover lens and identification tag.
Figure 10: Back Cover Lens and Identification Tag Removal
MN002465A01-AN
Chapter 5 : Maintenance
61
